American Industrial Hygiene Association (AIHA)

NOTE: Extrapolation to higher guidance levels for shorter exposure periods should not be attempted by use of the Haber relationship (expressing the product of exposure concentration and exposure duration as a constant), or modifications thereof, without specific validating data. The Haber relationship, with or without some of the proposed modifications, does not hold true over more than small differences in exposure time.(3) The ten Berge(4) extrapolation method can be used if there are sufficient data and expertise available to guide its implementation.

Value Development Considerations

ERPGs are determined on a case-by-case basis. Different chemicals will have different dose-response curves, can cause a wide variety of health effects, and will have different amounts and quality of toxicological data. There is no fixed formula for determining ERPG values, and no fixed relationship or ratio between the three ERPG values (ERPG-1, ERPG-2, ERPG-3) for any given chemical.

Development of ERPG values is through a weight-of-evidence approach resulting from review and deliberation on the available body of data. ERPG values are developed by comprehensive review of published and proprietary original source toxicological literature. In developing an ERPG for a chemical, it is important to emphasize the use of acute or short-term exposure data. When evaluating adverse health effects, both immediate and delayed health effects are considered. When adverse reproductive, developmental, or carcinogenic effects might be caused by a single exposure, the data are considered in the derivation of the ERPG.

Human exposure data are emphasized to the extent data are available. Unfortunately, human exposure data for acute chemical exposures are often anecdotal with unknown, estimated, or reconstructed levels of exposure. As a result, animal test data often form the basis for ERPG values.

The most pertinent information is derived from acute inhalation toxicity studies in animals that include analytical determination of exposure concentrations, clinical observations, and histopathology. The focus is on the highest experimental levels not showing the effects described by the definitions of the ERPG levels. In experimental data, the methods of concentration determination (i.e., nominal vs. analytical) are important considerations.

Data from repeated inhalation exposure studies, with clinical and pathologic examinations, are also considered. When inhalation toxicity data are unavailable or limited, data from studies involving other routes of exposure (such as ingestion or dermal) will be considered. More weight is given to rigorously conducted studies.

Finally, if mechanistic or dose-response data are available, these are applied as appropriate. In every data set, data considerations such as the method to determine concentration (e.g., nominal, analytical, modeling) and duration of exposure can be important.

Uncertainty Factors

When appropriate and when the data are sufficient, uncertainty factors are used when determining values for ERPG-1, ERPG-2, and ERPG-3. For all three ERPG levels, a default uncertainty factor of 10 is applied for interspecies extrapolation when it is appropriate, based on the weight of evidence found in data. Lesser factors may be applied if justified by sufficient data. Conversely, additional factors may be applied when the data are insufficient or when there are unusually sensitive members of the general population (e.g., a specific metabolic defect that makes some individuals unusually susceptible to the toxicity of the substance under consideration).

Carcinogenicity Considerations

To evaluate possible carcinogenic effects resulting from a single exposure to a carcinogen, the procedure described by the National Research Council (NRC), is used. If the data show the potential for carcinogenicity from long-term exposures to a chemical, the q1* calculation is performed. The q1* calculation consolidates risk estimates derived from low-dose extrapolation of animal bioassay or epidemiologic data into a single 1-hour exposure time frame and assumes a 1 in 10,000 risk of cancer. Where appropriate, physiologically-based pharmacokinetic approaches may be used to derive the risk estimates.

Sensitization Considerations

Users of this document are cautioned that there is no known or accepted threshold level at which persons sensitized to a chemical can be exposed without potentially experiencing an adverse skin- or respiratory-related effect. Therefore, the ERPGs may not offer protection for those who are sensitized to these kinds of chemicals.

Lethality Considerations

Uncertainty factors that may be used in the derivation of ERPGs are described below. These uncertainty factors are not absolute, but rather help to develop initial discussion points from which ERPGs may be derived.

The starting point for lethality considerations almost always begins with acute mammalian toxicity data. In examining such data, uncertainty factors must always be based on quality of the data, and therefore will be highly specific for the chemical under evaluation. Adequate evaluation of animal lethality data as they apply to humans includes a weight-of-evidence approach that requires considerable experience with such data and professional judgment. This evaluation is also dependent on the depth and quality of the data set.

Over the years of setting ERPGs, an empirical relationship was noted that the predicted threshold of human lethality (ERPG-3) consistently ranged near the value of 1/30 of the 1-hr LC(5), particularly for irritants. As more data were generated, it has been noted that the highest non-lethal level in animal studies ranged near the value of 1/3 of the 1-hr LC50. The application of a 10-fold interspecies uncertainty factor results in a total factor of 30 applied to the 1-hour LC50.

For less irritating chemicals, an uncertainty factor less than 30 might be applied to the 1-hr LC50. In other cases, the uncertainty factor might be greater than 30 because of a paucity of data or the poor quality of the data available for review.

Uncertainty factors of the type used for ERPG-3 have not been developed for ERPG-2 or ERPG-1 values. ERPG-3 values are based solely on lethality and ERPG-2 and ERPG-1 values can be based on several endpoints that may not be linked mechanistically.

ERPG-1 Odor Detection Indicator and Objectionable Odor

An odor detection indicator (yes or no) is shown with ERPG-1 values in the ERPG Table to indicate those chemicals that are likely to be detected by odor near their ERPG-1 value. This information is primarily intended for those emergency response agencies that incorporate into their planning the possibility that members of the public may call them when they detect an unusual chemical odor. This indicates only that a chemical will likely be detected by odor near its ERPG-1 value.

While a detectable odor may be indicated in the table for a specific ERPG-1 value, it should be understood that an ERPG-1 value can also be based on an airborne chemical concentration for a one-hour period below which only mild, transient adverse health effects are anticipated and that such health effects may or may not be associated with an objectionable or detectable odor. Furthermore, detection of an odor does not imply that a material is toxic at that level. Toxicity and odor detection have independent criteria. A substance may be toxic well below its odor threshold or exposures well above the odor threshold may be required to induce a toxic response.

Although the ERPG-1 definition incorporates the perception of a clearly defined objectionable odor, the property of an odor being objectionable is subjective, varies from one individual to another, and therefore is not often published. Data on odor threshold or detection levels are more commonly published. In the absence of information on an objectionable odor level, the Committee may use more conservative odor threshold or detection levels instead or may use these more conservative odor detection levels as a point of departure for estimating an objectionable level.

Lower Explosive Limit (LEL) Warnings

Lower Explosive Limit (LEL) warnings are also shown in the ERPG Table. These warnings serve to alert emergency managers and responders that an additional physical hazard may be present in addition to the toxicity hazards. The LEL warnings are presented where the ERPG values exceed 10%, 50%, or 100% of the LEL. In addition, an LEL column shows the LEL value in parts per million (ppm) when any of the ERPG values (also in ppm) exceeds any of the three LEL warning levels. The lack of an entry in the LEL column for any particular chemical should not be interpreted that the chemical is not flammable, but only that the ERPG values for that chemical do not exceed 10% of the LEL.

References

  1. U.S. Environmental Protection Agency / U.S. Federal Emergency Management Agency/ U.S. Department of Transportation: Technical Guidance for Hazards Analysis — Emergency Planning for Extremely Hazardous Substances. Washington, D.C.: U.S. Government Printing Office, December 1987.
  2. Code of Federal Regulations, Title 40, Part 68 — Accidental Release Prevention Requirements: Risk Management Programs Under the Clean Air Act, Section 112(r)(7); List of Regulated Substances and Thresholds for Accidental Release Prevention, Stay of Effectiveness; and Accidental Release Prevention Programs Under Section 112(r)(7) of the Clean Air Act as Amended, Guidelines; Final Rules and Notice.
  3. Haber, F.: Funf Vortrage aus den Jahren 1920–1923: No. 3, Die Chemie im Kriege, pp. 25-41; No. 5, Zur Geschichte des Gaskrieges, pp. 76-92. Berlin, Germany: Verlag von Julius Springer, 1924.
  4. ten Berge, W.F., A. Zwart, and L.M. Appleman: Concentration-Time Mortality Response Relationships of Irritant and Systemically Acting Vapours and Gases. J. Haz. Mater. 13:301–09 (1986).
  5. Rusch, G.M., C.B. Bast, and F.L. Cavender: Establishing a Point of Departure for Risk Assessment Using Acute Inhalation Toxicology Data. Reg. Tox. Pharmacol. 54:247–55 (2009).

Bibliography—Additional Background

  • American Industrial Hygiene Association (AIHA): Toxicology Committee: Emergency Exposure Limits. Am. Ind. Hyg. Assoc. J. 25:578–86 (1964).
  • American Institute for Chemical Engineers, Center for Chemical Process Safety, Emergency Response Planning Guidelines (ERPG), https://www.aiche.org/ccps/resources/glossary/process-safety-glossary/emergency-response-planning-guidelines-erpg
  • European Chemical Industry Ecology and Toxicology Centre (ECETOC): Emergency Exposure Indices for Industrial Chemicals (Technical Report No. 43). Brussels, Belgium: ECETOC, March 1991.
  • Jacobson, K.H.: AIHA Short-Term Values. Arch. Environ. Health 12:486–87 (1966).
  • Kelly, D.P. and F.L. Cavender: Emergency Response. In Encyclopedia of Toxicology, 2nd edition. Vol. 1. Wexler, P. (ed.). San Diego, Calif.: Academic Press, 2005.
  • National Institute for Occupational Safety and Health (NIOSH): Documentation for Immediately Dangerous to Life or Concentrations (IDLHs). Cincinnati, OH: NIOSH, latest edition.
  • National Institute for Occupational Safety and Health (NIOSH): NIOSH Pocket Guide to Chemical Hazards. Cincinnati, OH: NIOSH, latest edition.
  • National Oceanic and Atmospheric Administration, US Department of Commerce, Emergency Response Planning Guidelines (ERPGs), https://response.restoration.noaa.gov/oil-and-chemical-spills/chemical-spills/resources/emergency-response-planning-guidelines-erpgs.html
  • National Research Council, Commission on Life Sciences, Board on Environmental Studies and Toxicology, Committee on Toxicology: Criteria and Methods for Preparing Emergency Exposure Guidance Level (EEGL), Short-Term Public Emergency Guidance Level (SPEGL), and Continuous Exposure Guidance Level (CEGL) Documents. Washington, D.C.: National Academy Press, 1986.
  • National Research Council, Commission on Life Sciences, Board on Environmental Studies and Toxicology, Committee on Toxicology: Guidelines for Developing Community Emergency Exposure Levels for Hazardous Substances. Washington, D.C.: National Academy Press, 1993.
  • Ruijten, M.W.M.M., R. van Dorn, and A.P. van Harreveld: Assessment of Odour Annoyance in Chemical Emergency Management, RIVM report 609200001/2009. Bilthoven, RIVM, 2009.
  • Rusch, G.M.: The History and Development of Emergency Response Planning Guidelines. J. Haz. Mater. 33:192–202 (1993).
  • U.S. Department of Energy, DOE Handbook Temporary Emergency Exposure Limits for Chemicals: Methods and Practice, https://www.standards.doe.gov/standards-documents/1000/1046-BHdbk-2008/@@images/file
  • Woudenberg, F., and P. van der Torn: Emergency Exposure Limits: A Guide to Quality Assurance and Safety. Quality Assurance: Good Practice, Regulation, and Law 1(4):249–93 (1992).
